CSO Retinal Camera Cobra Plus

The Cobra PLUS is a non-mydatic fundus camera that compromises all the functions required for a rapid screening of the status of the retina.

DOWNLOAD CATALOG PRODUCT MANUAL

Compare

SKU: COBRA-PLUS Category: Retinal Camera Tags: Cobra Plus, Cobra Series, CSO, Fundus Camera, Retinal Camera

Description

Cobra PLUS allows the acquisition of multiple images, to create a panoramic image of the peripheral retinal areas. All images captured from COBRA + can be transferred to the Phoenix software which can obtain information and analysis.

Features

Shares the use of the CCD high resolution sensor
High precision focus control joystick
Capture images through a small pupil diameter (2.5mm)
Arteriolar to Venular width ratio
Simultaneous visible (‘white’) light and IR acquisition
Color inversion and filter simulation
Optional Electrical Tables

Manual guided acquisition system
Clear and detailed image of the ocular fundus
Field of vision of up to 50 degrees
Accurate and fast glaucoma screening
Infrared and color pictures of the retina
Panoramic analysis for enlarged field of view
Optional Tabletops and Monitors

Software

Infrared Image Acquisition
AVR Evaluation Module (optional)
Mosaic Function

Integration Tool with ERG Test
Cup to Disk Measurement
Multiple Wave-Length Images

Product Specifications

Working Distance: 20mm
Dimension: 420mm (w) x 315mm (l) x 255mm (h)
Field of View: 50° x 45°
Image Resolution: 2448 x 2051 (5M Pixel)
Weight: 6kg

Minimum Height - Chin Cup from Table:: 24xcm
Base Movement:: 105mm (w) x 110mm (l) x 30mm (h)
Auxiliary IR: LED @850nm
White Flash: LED @450-650nm

Power Supply

External Power Source: 24 VCC
In: 100-240 Vac - 50/60Hz - 0.9-05A
Out: 24Vdc - 40W

Power Net Cable: with plug C14
Frequency Range:: 80MHz - 800MHz
Isolation Transformer:: 230V / 230V

Video Demo

How to find us

Viewlight is a leading provider of medical practice equipment for ophthalmologists, optometrists and opticians.

8380 NW 64th St., Miami, Florida 33166
Phone: (305) 406-3915
Email: customerservice@viewlightusa.com

Ask a question

Additional information

Brand	CSO
Country of Origin	Made in Italy
Optional Accessories	Double Item Work Station , Single Item Work Station
Software	Phoenix
