Inami Digital Camera for Microscope Model 13S2C

Inami microscopes offers an optional USB digital camera Model 13S2C, offers a unique software where you can store and create your own patient data base to capture high quality digital photos and videos.

DOWNLOAD CATALOG

Description

Inami Digital Camera for Microscope Model 13S2C, is an easy to use and cost saving USB camera for operation microscopes devices offered with a high resolution detailed images and smooth video recordings. The ergonomic design of Digital Camera – 13S2C provides a clear and detailed images and videos while observing all patients eye.

Overview

Frame Rate: Cross-angle Stereo Vision
Lens Mount: CS-mount
Pixel Size: 3.75
Resolution: 1296 × 964
Sensor Type: CCD
Sensor Format: 1/3"

ADC: 12-bit
Chroma: Color
Megapixels: 1.3
Readout Method: Global shutter
Sensor Name: Sony ICX445
Required Accessories: Lens, Cable, Host Adapter (USB)

Features

Processing: Color/Greyscale, gamma, white balance
Serial Port: 1 (over non-isolated I/O)
Flash Memory: 256 KB non-volatile memory
Trigger Modes: Standard, bulb, skip frames, overlapped

User Sets: 2 memory channels - camera settings
Exposure Range: 0.01 ms to 10 seconds
Gain Range: 0 dB to 24 dB
Partial Image Modes: Pixel binning, ROI

Physical

Auxiliary Output: 3.3 V, 150 mA maximum
Interface: USB 2.0

Weight: 37 grams
Dimensions: 25.5 mm × 44 mm × 41 mm

Power

Power Consumption: 2 W
Hard Drive: 200 MB hard drive space
RAM: 2 GB RAM or more

Port: USB 2.0 Port
Operating System: Windows or Linux (32–bit or 64–bit)
CPU: 3.1 GHz or equivalent CPU
